Vertiv Liebert GXT5 UPS – 4900VA/4600W 208V | Online Rack Tower Energy Star
Login to View Prices
The Vertiv Liebert GXT5 uninterruptible power supply (UPS) protects critical equipment against outages and every type of power disturbance. This 4900VA online double conversion UPS offers continuous power conditioning in centralized and edge locations. With high power factor (0.9-1.0), it allows more connected loads saving space and costs. This tower/rack mount UPS has an optional Vertiv RDU101 communications card for remote monitoring to help you make more informed decisions and faster event resolution. With the free Vertiv Power Insight software, you can consolidate your view of up to 100 distributed UPS units providing simple notification of status and events in a single pane of glass. This 208V in/ 208V out single phase UPS has scalable runtime options with matching external battery cabinets to give extra runtime during an outage to support critical equipment. This battery backup is ENERGY STAR 2.0 certified and comes with an intuitive gravity sensing full-color LCD display.
- HIGH POWER FACTOR (0.9-1.0): More usable power allows more connected loads saving space and costs.
- REMOTE MANAGEMENT: Optional Vertiv RDU101 network communications card with advanced features.
- 3-YEAR WARRANTY: 3-year comprehensive coverage including battery with options for 2-year extension.
- ENERGY EFFICIENT (up to 95%): Energy Star 2.0 certified with high normal operating efficiency.
- EASY-TO-USE INTERFACE: Tower/rack mount design with gravity sensing graphical color display.
Additional information
| Weight | 149.1000 lbs |
|---|---|
| Environmental Sensors | Leak Detection Sensor,Temperature Sensor,Humidity Sensor |
| Number of External Battery | 1 |
| Package Contents | <ul> <li>GXT5 6k L630 UPS</li> <li>4 Post Fixed Rail Kit</li> <li>Tower Stand</li> <li>USB Cable</li> <li>Quick Start Guide</li> <li>Safety Instruction Manual </li> </ul> |
| Backup/Run Time With Extern | 9.50 Minute |
| Utility (AC) Mode Overload | <ul> <li>105% to 125% for 5 minutes </li> <li>125% to 150% for 60 seconds</li> <li>>150% (impact load) minimum 200 ms</li> </ul> |
| Application/Usage | Mission Critical Equipment,Data Center |
| Status Indicators | <p><b>LED/Full Color Graphic LCD:</b></p> <ul> <li>Alarm / Fault Indication</li> </ul> |
| Phase | Single Phase |
| Battery Chemistry | Lead Acid |
| Input Frequency | 50 Hz |
| Load Capacity (Watt) | 4900 W |
| Receptacle Type | Hardwired,IEC 60320 C19,IEC 60320 C13 |
| Transfer Time | 0 ns |
| Receptacle Detail | 2 x IEC 60320 C19,6 x IEC 60320 C13 |
| Backup/Run Time (Half Load) | 14.50 Minute |
| Serial Port | Yes |
| USB | Yes |
| Input Voltage | 230 V AC |
| Load Capacity (VA) | 4900 VA |
| Waveform Type | Pure Sine Wave |
| Form Factor | Rack/Tower |
| Hot Swappable | Yes |
| Rack Height | 5U |
| Backup/Run Time (Full Load) | 5.50 Minute |
| TAA Compliant | No |
| Product Series | GXT |
| Plug/Connector Type | Hardwired |
| Manufacturer Website Addres | |
| Manufacturer | Vertiv |
| Network (RJ-45) | Yes |
| Limited Warranty | 3 Year |
| Output Voltage | 208 V AC |
| Energy Star | Yes |
| Product Type | Double Conversion Online UPS |
| Packaged Quantity | 1 |
| Battery Characteristics | Valve-regulated |
| Environmentally Friendly | Yes |
| Country of Origin | China |
| UPC | 0 |
| MPN | GXT5-6KL630RT5UXLN |
| Brand | Liebert |
